Product Introduction

Product Features

• Dual compression algorithm: video compression support H.265/H.264;

• Fast deployment and control: The system is designed to be lightweight and portable for a single soldier, which can realize fast and free deployment and control within 5 minutes;

• Self-built network: no need to rely on public network transmission, supports seamless interfacing with satellite, fiber and 5G;

• Centerless co-channel networking: All nodes have equal status, i.e., they can act as terminal nodes, relay nodes or central nodes, and can quickly establish wireless communication networks without relying on wired communication lines;

• Arbitrary network topology: MESH wireless self-assembly system supports any network topology, such as point-to-multipoint, chain relay, mesh network and hybrid network, etc;

• Destruction tolerance: MESH wireless self-assembly system does not affect the whole network when a single node device fails;

• Support infrared night vision function using imported infrared lamp array, the service life of up to 30,000 hours, night vision distance of 50-80 meters;

• Security and confidentiality: The system can effectively prevent illegal users from intruding into the network by setting the working frequency, carrier bandwidth, scrambling code (i.e. MESHID), communication distance and networking mode, etc. The system also supports AES128/AES256 (source encryption);

• Anti-interference: External filters can be used to effectively suppress out-of-band harmonic interference and improve signal immunity and signal-to-noise ratio. Meanwhile, ARQ (Automatic Retransmission Request) transmission mechanism is adopted to reduce data transmission loss rate and improve data transmission reliability. In addition, it comes with frequency sweeping function, which can be manually configured to set the central frequency point with less influence by interference according to the sweeping result of the allocated central frequency point to achieve interference frequency avoidance;

Centerless Networking

Nodes with equal status can serve as terminal nodes, relay nodes or central nodes. Nodes automatically identify and select the optimal route for bandwidth data.

Diagram

Application

Wireless broadband communications are provided for "peace and emergency" tasks such as emergency response, anti-terrorism and riot prevention, covert reconnaissance, special operations, emergency rescue and disaster relief, daily patrols, and firefighting.
