Electrical  property parameter

Frequency  range (MHz)

1240-1300MHz

1370-1470MHz

Test condition

Tape test

Standing  wave ratio

≤2

dBi  gain

2(typical value)

Input impedance (Ω)

50Ω

Polarization  mode

vertical

Power  capacity

20W

Physical  characteristic parameter

dimension

See  the drawing

Interface  processing mode

N-J

Antenna  cover material

Glass  reinforced plastic

weight

≤200g

Product  label information

Radium  carving is located on the surface of glass steel tube at the root of antenna

Radium  carving content is divided into three lines: 1. STA1214B-2; 2.1240~1470MHz,  2dBi; 3.SN number

color

black

Reliability  parameter

Operating  temperature

-40~70℃

Working  humidity

5%-95%

Storage  temperature

-50~75℃
