The MB36Pro Manpack Mesh Radio integrates advanced COFDM modulation, self-healing IP Mesh networking, and IFS/FHSS frequency hopping technology to deliver secure, high-speed wireless communications. Designed for tactical missions, emergency response, public safety, and industrial operations, it supports over 64 mesh nodes with AES128/256 encryption.
MB36Pro Manpack Mesh Radio
High-Performance COFDM IP Mesh Radio for Mission-Critical Communications
The MB36Pro Manpack Mesh Radio is a rugged portable wireless communication system designed for reliable broadband networking in complex and infrastructure-free environments. Combining COFDM modulation, self-forming IP Mesh networking, and IFS/FHSS frequency hopping technology, it ensures uninterrupted voice, video, an, data transmission for demanding field operations.
With up to 52 Mbps throughput, 20 km line-of-sight transmission, and support for more than 64 mesh nodes, the MB36Pro enables rapid deployment of resilient wireless networks for military, emergency response, law enforcement, disaster relief, and industrial applications.
Key Features
Advanced COFDM Broadband Transmission
Built on COFDM wireless transmission technology, the MB36Pro delivers excellent anti-interference capability, stable non-line-of-sight communication, and reliable broadband connectivity in urban, mountainous, and forest environments.
Intelligent IP Mesh Networking
The self-forming and self-healing Mesh architecture automatically establishes multi-hop communication without centralized infrastructure.
Benefits include:
Support for 64+ Mesh Nodes
Automatic route optimization
Multi-hop relay communication
Dynamic topology adjustment
Rapid network recovery
IFS / FHSS Frequency Hopping Technology
TThe integrated Intelligent Frequency Selection (IFS) and Frequency Hopping Spread Spectrum (FHSS) technologies significantly improve spectrum efficiency and communication reliability.
Advantages include:
Enhanced anti-jamming capability
Reduced co-channel interference
Stable communication in congested RF environments
Improved communication security
High-Speed Broadband Transmission
The MB36Pro supports:
Peak Data Rate up to 52 Mbps
Real-time HD video transmission
Voice communication
Ethernet data networking
Command & control applications
Defense-Grade Security
To ensure secure wireless communication, the system supports:
AES128 Encryption
AES256 Encryption
Secure IP Mesh Routing
Protected Tactical Communication
Rugged Portable Design
Designed for field deployment, the MB36Pro features:
Compact manpack structure
IP66 protection rating
Lightweight design (≤2 kg)
Operating temperature from -30°C to +65°C
Suitable for all-weather outdoor operations.
Technical Highlights
| Feature | Specification |
|---|---|
| Wireless Technology | COFDM Broadband Mesh |
| Networking | Self-forming IP Mesh |
| Mesh Capacity | 64+ Nodes |
| Frequency Hopping | IFS / FHSS |
| Encryption | AES128 / AES256 |
| Peak Data Rate | 52 Mbps |
| RF Power | 4W (2W ×2) |
| LOS Distance | Up to 20 km |
| Protection | IP66 |
| Battery | 25.2V Removable Lithium Battery |
| Startup Time | Approximately 5 Seconds |
Typical Applications
Why Choose MB36Pro?
Advanced COFDM Broadband Technology
Self-Healing Mesh Networking
AES128/256 Secure Encryption
High-Speed 52 Mbps Transmission
More than 64 Mesh Nodes
Long-Distance Communication
Rugged IP66 Design
Rapid Deployment Within Minutes
Designed for Mission-Critical Applications
FAQ
Q1. What wireless technology does the MB36Pro use?
The MB36Pro utilizes COFDM broadband transmission combined with self-forming IP Mesh networking, providing stable, high-capacity wireless communication in both LOS and challenging environments.
Q2. How many mesh nodes can the network support?
The system supports more than 64 mesh nodes, allowing flexible deployment for medium and large-scal, wireless communication networks.
Q3. Does the MB36Pro support frequency hopping?
Yes. It supports Intelligent Frequency Selection (IFS) and FHSS frequency hopping technology, improving anti-jamming capability and communication reliability.
Q4. What security features are included?
The MB36Pro supports AES128 and AES256 encryption to protect voice, video, and data transmission against unauthorized access.
Q5. What applications is the MB36Pro suitable for?
It is widely used in military communications, emergency response, disaster recovery, public safety, law enforcement, border security, industrial operations, and temporary wireless networks.
Q6. Can the MB36Pro operate in harsh environments?
Yes. With an IP66-rated enclosure and an operating temperature range from -30°C to +65°C, it is designed for reliable outdoor operation in demanding environments.
